API 5CT L80-9Cr Casing and Tubing
Short Description:
Durable API 5CT L80-9Cr casing and tubing with high corrosion resistance for sour gas wells. Ideal for CO₂ and H₂S environments.
L80-9Cr Casing and Tubing:
L80-9Cr casing and tubing are premium-grade OCTG products manufactured in accordance with API 5CT specifications. Featuring 9% chromium content, this material offers superior resistance to CO₂ and H₂S corrosion, making it ideal for sour service applications in oil and gas wells. With excellent mechanical strength and a quenched and tempered heat treatment, L80-9Cr ensures long-term performance in high-pressure, high-temperature environments. Available in a full range of sizes, thread types, and length ranges (R1–R3), our L80-9Cr pipes meet the demanding needs of offshore and deep well projects.
Specifications of L80 9Cr Tube:
| Specifications | API 5CT |
| Grade | 9Cr,13Cr,etc. |
| Type | Seamless |
| Tubing Dimensions | 26.7 mm (1.05 Inch) to 114.3 mm (4.5 Inch) |
| Casing Dimensions | 114.3 mm (4.5 Inch) to 406.4 mm (16 Inch) |
| Length | 5.8M,6M & Required Length |
| API 5L | API 5L GR.46 / 42 / 52 / 60 / 56 / 65 / 80/ 70 |
| Mill Test Certificate | EN 10204 3.1 or EN 10204 3.2 |
API 5CT L80 9Cr Pipes Chemical Composition:
| Grade | C | Si | Mn | Cr | Mo |
L80 9cr |
0.15 | 0.50 | 1.0 | 8.0-10.0 | 0.8-1.2 |
Mechanical Properties of API 5CT L80 9Cr Pipes & Tubes:
| Grade | Tensile Strength (MPa) | Hardness | Yield Strength (MPa) |
| API 5CT L80 9cr | 655 | 23-25HRC | 552-758 |
API 5CT Production Tubing Size
| 1/2 Inch IPS(.840 Inch Outer Diameter) | 6 Inch IPS(6.625 Inch Outer Diameter) |
| Schedule 80, 40, 10, 5, XXH, 160 | Sched |
| 1/8 Inch IPS(.405 Inch Outer Diameter) | 3 1/2 Inch IPS( 4 Inch Outer Diameter) |
| 3/8 Inch IPS(.675 Inch Outer Diameter) | 5 Inch IPS( 5.563 Inch Outer Diameter) |
| Schedule 10, 40, 80, 160, XXH | Schedule-40 |
| Schedule 40, 80 | Schedule 10, 40, 80, 160, XXH |
| 1/4 Inch IPS(.540 Inch Outer Diameter) | 4 Inch IPS(4.500 Inch Outer Diameter) |
| Schedule 10, 40, 80 | Schedule 10, 40, 80, 160, XXH |
| 3 Inch IPS( 3.500 Inch Outer Diameter) | Schedule 5, 10, 40, 80, 160, XXH |
| Schedule 10, 40, 80 | Schedule 10, 40, 80, 160, XXH |
| 3/4 Inch IPS(1.050 Inch Outer Diameter) | 8 Inch IPS(8.625 Inch Outer Diameter) |
| Schedule 10, 40, 80, 160, XXH | Schedule 5, 10, 40, 80, 120, 160, XXH |
| 1 Inch IPS:(1.315′ Outer Diameter) | 10 Inch IPS(10.750 Inch Outer Diameter) |
| Schedule 5, 10, 40, 80, 160, XXH | Schedule 10, 20, 40, 80 (.500), TRUE 80(.500) |
| 2 Inch IPS(2.375 Inch Outer Diameter) | 16 Inch IPS(16.000 Inch Outer Diameter) |
| 1-1/4 Inch IPS(1.660 Inch Outer Diameter) | 12 Inch IPS(12.750 Inch Outer Diameter) |
| 1-1/2 Inch IPS(1.900 Inch Outer Diameter) | 14 Inch IPS(14.000 Inch Outer Diameter) |
| Schedule 10, 40, 80, 160, XXH | Schedule10 (.188), Schedule40 (.375) |
| 2 1/2 Inch IPS(2.875 Inch Outer Diameter) | 18 Inch IPS (18.000 Inch Outer Diameter) |
| Schedule 10, 40, 80, 160, XXH | Schedule 10, 20, 40(.375), TRUE40(.406), Schedule80(.500) |
| Schedule 10, 40, 80, 160, XXH | Schedule10(.188), Schedule40(.375) |
Applications of API 5CT L80 9Cr Oil Tubing:
1.Sour gas and acid gas wells
2.CO₂ and H₂S corrosion environments
3.High-pressure, high-temperature (HPHT) wells
4.Offshore oilfield operations
5.Geothermal drilling projects
Why Choose Us?
• You can get the perfect material according to your requirement at the least possible price.
• We also offer Reworks, FOB, CFR, CIF, and door to door delivery prices. We suggest you to do deal for shipping which will be quite economical.
• The materials we provide are completely verifiable, right from raw material test certificate to the final dimensional statement.(Reports will show on requirement)
• You can get the perfect material according to your requirement at the least possible price.
• We also offer Reworks, FOB, CFR, CIF, and door to door delivery prices. We suggest you to do deal for shipping which will be quite economical.
• The materials we provide are completely verifiable, right from raw material test certificate to the final dimensional statement.(Reports will show on requirement)
Oil Tube Packaging:
1. Packing is quite important especially in a case of international shipments in which consignment pass through various channels to reach the ultimate destination, so we put special concern regarding packaging.
2. Saky Steel's pack our goods in numerous ways based on the products. We pack our products in multiple ways, such as,
