API 5CT L80 13cr Oil Casing and Tubing
Short Description:
High-strength API 5CT L80 13Cr oil casing and tubing for demanding oil and gas applications. Corrosion-resistant, durable, and API certified for offshore and deep well drilling. Customizable with fast delivery options.
API 5CT L80 13cr Oil Casing and Tubing:
API 5CT L80 13Cr Oil Casing and Tubing is designed for demanding oil and gas exploration environments, offering exceptional corrosion resistance and high strength. Manufactured from 13Cr steel, this casing and tubing ensures durability against harsh conditions, including high H2S and CO2 environments. With API 5CT certification, it meets industry standards for quality and reliability. Ideal for offshore drilling and deep well applications, our 13Cr casing provides superior performance, extended service life, and customization options to suit your project needs. Fast delivery and global shipping available.
Specifications of API 5CT L80 Tube:
| Specifications | API 5CT |
| Grade | L80 13Cr |
| Type | Seamless |
| Tubing Dimensions | 26.7 mm (1.05 Inch) to 114.3 mm (4.5 Inch) |
| Casing Dimensions | 114.3 mm (4.5 Inch) to 406.4 mm (16 Inch) |
| Length | 5.8M,6M & Required Length |
| API 5L | API 5L GR.46 / 42 / 52 / 60 / 56 / 65 / 80/ 70 |
| Mill Test Certificate | EN 10204 3.1 or EN 10204 3.2 |
API 5CT L80 13Cr Pipes Chemical Composition:
| Grade | C | Si | Mn | S | P | Cr | Ni | Mo | Mo | Cu |
API 5CT L80 13cr |
0.23 | 0.10-0.60 | 0.3-1.0 | 0.020 | 0.020 | 12.0-14.0 | 0.50 | 0.10-0.50 | 0.10-0.50 | 0.35 |
Mechanical Properties of API 5CT L80 13Cr Pipes & Tubes:
| Grade | Tensile Strength (MPa) | Elongation (%) min | Yield Strength 0.2% Proof (MPa) min |
| API 5CT L80 13cr | 655 | 20 | 552-655 |
API 5CT Grade L80 Pipe Size Chart in mm
| 1/2 Inch IPS(.840 Inch Outer Diameter) | 6 Inch IPS(6.625 Inch Outer Diameter) |
| Schedule 80, 40, 10, 5, XXH, 160 | Sched |
| 1/8 Inch IPS(.405 Inch Outer Diameter) | 3 1/2 Inch IPS( 4 Inch Outer Diameter) |
| 3/8 Inch IPS(.675 Inch Outer Diameter) | 5 Inch IPS( 5.563 Inch Outer Diameter) |
| Schedule 10, 40, 80, 160, XXH | Schedule-40 |
| Schedule 40, 80 | Schedule 10, 40, 80, 160, XXH |
| 1/4 Inch IPS(.540 Inch Outer Diameter) | 4 Inch IPS(4.500 Inch Outer Diameter) |
| Schedule 10, 40, 80 | Schedule 10, 40, 80, 160, XXH |
| 3 Inch IPS( 3.500 Inch Outer Diameter) | Schedule 5, 10, 40, 80, 160, XXH |
| Schedule 10, 40, 80 | Schedule 10, 40, 80, 160, XXH |
| 3/4 Inch IPS(1.050 Inch Outer Diameter) | 8 Inch IPS(8.625 Inch Outer Diameter) |
| Schedule 10, 40, 80, 160, XXH | Schedule 5, 10, 40, 80, 120, 160, XXH |
| 1 Inch IPS:(1.315′ Outer Diameter) | 10 Inch IPS(10.750 Inch Outer Diameter) |
| Schedule 5, 10, 40, 80, 160, XXH | Schedule 10, 20, 40, 80 (.500), TRUE 80(.500) |
| 2 Inch IPS(2.375 Inch Outer Diameter) | 16 Inch IPS(16.000 Inch Outer Diameter) |
| 1-1/4 Inch IPS(1.660 Inch Outer Diameter) | 12 Inch IPS(12.750 Inch Outer Diameter) |
| 1-1/2 Inch IPS(1.900 Inch Outer Diameter) | 14 Inch IPS(14.000 Inch Outer Diameter) |
| Schedule 10, 40, 80, 160, XXH | Schedule10 (.188), Schedule40 (.375) |
| 2 1/2 Inch IPS(2.875 Inch Outer Diameter) | 18 Inch IPS (18.000 Inch Outer Diameter) |
| Schedule 10, 40, 80, 160, XXH | Schedule 10, 20, 40(.375), TRUE40(.406), Schedule80(.500) |
| Schedule 10, 40, 80, 160, XXH | Schedule10(.188), Schedule40(.375) |
Applications of API 5CT L80 13Cr Oil Tubing:
1.Offshore and deep well drilling
2.Sour gas (H2S) and CO2-rich environments
3.Well completion and integrity maintenance
4.High-pressure, high-temperature wells (HPHT)
5.Enhanced oil recovery (EOR) operations
6.Sour service applications in the oilfield
Why Choose Us?
• You can get the perfect material according to your requirement at the least possible price.
• We also offer Reworks, FOB, CFR, CIF, and door to door delivery prices. We suggest you to do deal for shipping which will be quite economical.
• The materials we provide are completely verifiable, right from raw material test certificate to the final dimensional statement.(Reports will show on requirement)
• You can get the perfect material according to your requirement at the least possible price.
• We also offer Reworks, FOB, CFR, CIF, and door to door delivery prices. We suggest you to do deal for shipping which will be quite economical.
• The materials we provide are completely verifiable, right from raw material test certificate to the final dimensional statement.(Reports will show on requirement)
API 5CT L80 13Cr Oil Tube Packaging:
1. Packing is quite important especially in a case of international shipments in which consignment pass through various channels to reach the ultimate destination, so we put special concern regarding packaging.
2. Saky Steel's pack our goods in numerous ways based on the products. We pack our products in multiple ways, such as,
