304H Stainless Steel Spring Wire
Short Description:
Specifications of Stainless Steel Spring Wire:
Specifications : ASTM A313, AMS 5688
Grade: 304, 304H, 316
Wire diameter : 0.1 to 5.0mm
Surface: Bright, Dull
304H Stainless Spring Wire Chemical Composition:
Grade | C | Mn | Si | P | S | Cr | Cu | Ni | N |
304H | 0.04-0.10 | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 18.0 – 20.0 | 0.50 max | 8.0- 11.0 max | 0.15 max |
304H Stainless Spring Wire Stock From SakySteel:
Material | Surface | Wire Diameter | Inspection Certificate |
304H | Dull & Bright | Φ0.4-Φ0.45 | TSING & YongXing & WuHang |
304H | Dull & Bright | Φ0.5-Φ0.55 | TSING & YongXing & WuHang |
304H | Dull & Bright | Φ0.6 | TSING & YongXing & WuHang |
304H | Dull & Bright | Φ0.7 | TSING & YongXing & WuHang |
304H | Dull & Bright | Φ0.8 | TSING & YongXing & WuHang |
304H | Dull & Bright | Φ0.9 | TSING & YongXing & WuHang |
304H | Dull & Bright | Φ1.0-Φ1.5 | TSING & YongXing & WuHang |
304H | Dull & Bright | Φ1.6-Φ2.4 | TSING & YongXing & WuHang |
304H | Dull & Bright | Φ2.5-4.0 | TSING & YongXing & WuHang |
Stainless Steel Spring Wire Tensile Strength:
Wire Diameter |
JIS | ASTM | JIS-WPB | ASTM | JIS-WPC | ASTM |
SUS-302 | 316 | SU-302 | 302CLass1 | 631J1 | 631 | |
SUS304 | SUS-304 | 304 | ||||
316 | ||||||
0.08-0.2 | 1650-1900 MPa | 1 690- 1895 MPa | 2150-2400 MPa | 2240-2450 MPa | 1950-2200 MPa | |
0.23-0.4 | 1600-1850 MPa | 1655-1810 MPa | 2050-2300 MPa | 2205-2330 MPa | 1930-2180 MPa | 2032 MPa |
0.45-0.6 | 1600-1850 MPa | 1620- 1825 MPa | 1 950-2200 MPa | 2070-2220 MPa | 1850-2100 MPa | 1965 MPa |
0.65-1.0 | 1530-1780 MPa | 1520-1825 MPa | 1850-2100 MPa | 1995-2095 MPa | 1800-2050 MPa | 1895 MPa |
1.2-1.4 | 1450-1700 MPa | 1550-1760 MPa | 1750-2000 MPa | 1840-2020 MPa | 1700-1950 MPa | 1826 MPa |
16-2.0 | 1400-1700 MPa | 1480-1 666 MPa | 1650-1900 MPa | 1735-1895 MPa | 1600-1850 MPa | 1770 MPa |
2.3-2.6 | 1320-1570 MPa | 1 380- 1585 MPa | 1 550-1800 MPa | 1 640-1805 MPa | 1500-1750 MPa | 1670 MPa |
2.9-4.0 | 1230-1480 MPa | 1275-1450 MPa | 1450-1700 MPa | 1560-1670 MPa | 1400-1650 MPa | 1625 MPa |
4.5-6.0 | 1100-1350 MPa | 1105- 1275 MPa | 1350-1600 MPa | 1335-1475 MPa | 1300-1550 MPa | 1545 MPa |
Why Choose Us :
1. You can get the perfect material according to your requirement at the least possible price.
2. We also offer Reworks, FOB, CFR, CIF, and door to door delivery prices. We suggest you to do deal for shipping which will be quite economical.
3. The materials we provide are completely verifiable, right from raw material test certificate to the final dimensional statement.(Reports will show on requirement)
4. e guarantee to give a response within 24hours(usually in the same hour)
5. You can get stock alternatives, mill deliveries with minimizing manufacturing time.
6. We are fully dedicated to our customers. If it will not possible to meet your requirements after examining all options, we will not mislead you by making false promises which will create good customer relations.
SAKY STEEL’S Quality Assurance (including both Destructive and Non-Destructive) :
1. Visual Dimension Test
2. Mechanical examining like tensile, Elongation and reduction of area.
3. Impact analysis
4. Chemical examination analysis
5. Hardness test
6. Pitting protection test
7. Penetrant Test
8. Intergranular Corrosion Testing
9. Roughness Testing
10. Metallography Experimental Test
SAKY STEEL’S Packaging:
1. Packing is quite important especially in a case of international shipments in which consignment pass through various channels to reach the ultimate destination, so we put special concern regarding packaging.
2. Saky Steel’s pack our goods in numerous ways based on the products. We pack our products in multiple ways, such as,
